Ultra-sorb steam dispersion panels

Guaranteed, short non-wetting distances.

• Install within inches of downstream devices.
Rapid, drip-free steam absorption means steam does not condense on downstream devices.

Efficient by design

• Reduce wasted energy and condensate up to 85%.
High-Efficiency Insulated Tubes significantly reduce airstream heat gain and condensate production. (Standard on Model XV; optional on Models LV and LH.)

• Higher capacities per tube increase efficiency, reduce cost.
Insulated dispersion tubes produce less condensate and, therefore, have more steam available for humidification, increasing the capacity of each tube. As a result, fewer tubes may be required to meet application requirements, further lowering condensate production and heat gain while reducing resource consumption and cost.

• No steam jackets; no unnecessary heat gain.
When there is no call for humidity, Ultra-sorb panels are at duct temperature while conventional jacketed steam injection systems stay hot and continue to add heat to the airstream.

Lowest installation cost

• Factory assembly eases installation.
Panels ship preassembled and install quickly with easy mounting, steam, and condensate connections.

Model XV: Highest performance

Integral condensate management.

An industry first for pressurized steam, Ultra-sorb Model XV vaporizes dispersion-generated condensate and returns pressurized condensate to the boiler without additional pumps, valves, vents, or controls.

Most efficient dispersion.

• Zero water waste.
All condensate returns to the boiler while still hot, saving energy, water, and boiler chemicals.
• Lowest heat gain.
High-Efficiency Insulated Tubes and an insulated steam delivery header reduce airstream heat gain by up to 85%.

Models LV and LH: Most versatile

Disperse pressurized or nonpressurized steam.

Models LV and LH disperse steam generated by pressurized steam boilers or by nonpressurized steam generators such as DRI-STEEM's GTS®, STS, Vaporstream®, Vapormist®, and XT humidifiers.

Wide capacity range and options

• Nominal steam capacity up to 4,000 lbs/hr (1814 kg/h)
• High-Efficiency Insulated Tubes option
• 316 stainless steel construction option
